Ferry 75

100 passengers ferry with economy and first class sections

The Ferry 75 is a sea going ferry with a seating capacity for 100 passengers divided into two separate air conditioned sections. An economy class section with high quality comfortable armchair seats for 88 passengers and a luxury lounge for 12 VIP passengers. The boat comes with a crew cabin with 4 bunk beds.

Especificações

Length Overall : 22.9 mtr
Length Waterline : 20.0 mtr
Beam : 6.5 mtr
Hull Depth : 2.9 mtr
Draft : 0.8 mtr
Displacement : 45 ton
Hull and deck materials : GRP
Fuel capacity : 2 x 3,000 liter aluminum fuel tank
Water capacity : 1 x 500 liter aluminum water tank
Standard Engines : Yanmar 2x830 HP inboard diesel
Drive : Conventional direct shaft
Passengers capacity : 100 passengers (88 coach class + 12 VIP class)

Construção

O casco e o convés são feitos de um molde GRP de peça única, construído a partir da combinação de esteira de fios picados, tecido de malha bidirecional e núcleo de balsa laminado à mão sob temperaturas controladas com resina de poliéster isoftálica.
O exterior do casco e do convés tem acabamento em gel-coat com esmalte espelhado.
The hull is stiffened with GRP molded frames filled with polyurethane and bonded to hull bottom
No deck, a balsa é substituída por compensado para suportar os encaixes do deck.
Todos os materiais utilizados na construção são de qualidade marítima aprovada
Cor padrão do casco: branco

Características padrão

Temperature controlled FRP main cabin covered by tempered marine glass with luxury seats for 88 passengers.
Separate luggage room at aft for 100 large size bags.
One separate VIP luxury lounge cabin with leather rounded sofa seat for 12 persons with LCD screen, kitchen galley with fridge and oven, dedicated toilet cabinet with sink.
One crew room on the V-Berth with 4 bunk beds and one toilet with shower.
Two toilet cabinets with sink on the back side of the main cabin.
Air condition system 70,000 BTU.
Marine Generators 2 nos x 25 KW with 1 AC/DC Switchboard panel on the dash board.
Electrical Windlass 1,700 watts with Anchor and 100Mtr Galvanized Chain.
Liferafts for 100 passengers
Standard Navigation Equipment (GPS, Radar and VHF Radio)
Non-skid flooring
Marine grade horns
Navigation lights
Remote controlled search light
Bússola
Bollards x 8 nos
Windscreen wipers x 2 nos
Bow railing in stainless steel.
Shore Power socket
